High voltage 96volt 192V 384V 400V 100ah Lithium Battery 10kwh 20kwh 40kwh Lifepo4 Rechargeable Battery Pack
| 1.Battery Module Parameters | ||
| Item | Parameters | Remark |
| Nominal Capacity | 200Ah | 0.2C discharge;Cut-off voltage 37.5V |
| Energy | 10240Wh | |
| Nominal Voltage | 51.2V | |
| Factory Voltage | 51.2-58.4V | |
| Internal Resistance | 50m | After standard charge AC 1KHz test |
| Charge Voltage | 58.4V±0.2V | CC/CV |
| Standard Charge Current | 0.2C | |
| Max Charge Current | 1C | |
| Standard Discharge Current | 20A | |
| Max Discharge Current | 150A | |
| Discharge Cut-off Voltage | 44.8V | |
| Working Temperature | 0~+45℃,Charge;-10~+70℃,Discharge | |
| High Temperature Static | 80℃ 48h | |
| Storage Temperature | 0℃~+45℃,<one month;15℃~+35℃,<six months | |
| Weight | 170kg | |
| Finished Product Size | 1050*600*600mm | |
| 2.Inverter Parameters | ||||
| 1 | Inverter | Rated Power | 5KVA | |
| 2 | Instantaneous power(20ms) | 15kw | ||
| 3 | Output Waveform | Pure Sine Wave | ||
| 4 | Output Voltage | 220VAV(±10%) | ||
| 5 | Output Frequency | 50Hz/60Hz(Auto detect) | ||
| 6 | Inverter Efficiency(Maximum) | >95%(Rated load, when battery pack is full) | ||
| 7 | Conversion Time | 10ms(UPS typical conversion time)20ms(Load conversion time) | ||
| 8 | Communication Interface | With RS232 and USB data transmission interface | ||
| 9 | Screen Display Data | LED Screen display data | ||
| 10 | Input Control | Support 220V AC input and solar panel and bypass voltage charging input. | Automatic switching | |
Products Description：
This product is composed of high quality lithium iron phosphate core (series-parallel connection) and advanced BMS management system. It can be used as independent DC power supply or as "basic unit" to form a variety of energy storage lithium battery power supply systems.
It has high reliability and long life. Products developed for applications such as power grid energy storage,industrial and commercial energy storage, home high voltage energy storage, high voltage UPS, and data room.
Product Advantage
Convenient installation and maintenance, easy operation
The product adopts modular design, higher integration, saving installation space; adopts high performance lithium iron phosphate cathode material, good core consistency, design service life of more than 10 years; one-key switch machine, front operation, front
wiring
High energy lithium electric equipment
Achieve higher energy supply, lower energy consumption, and reduce environmental pollution; adopt all-round, multi-level battery protection strategy and fault isolation measures to ensure the safe operation of the system.
Guangzhou ESG Energy Technology Co., Ltd. is mainly committed to the development,
production and sales of pure sine wave off-grid inverter, solar controller and solar lighting, lithium battery energy storage battery
and other wind-solar complementary power generation system products.
With the progress of solar cell technology and the development of low power semiconductor design technology,
the application of solar cell instead of traditional battery gradually appeared. With the service concept of "innovation in science and technology,
quality assurance, value creation for customers", under the guidance and innovation of professional R & D personnel,
with the exquisite appearance and superior electrical performance of EsenGAu products,
we have established friendly cooperative relations with various power supply companies and power plants in China power system. At the same time,
we also developed a wide range of foreign markets, and our products are exported to Japan, South Korea, the United States, Europe, Australia and other places.
