ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
Application:
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
Equipped with PWM solar charge controller to maximize and regulate Dc power from the solar
array for the charging the battery bank.
Transformer-less design provides reliable power conversion in compact size and with high
efficiency.With aluminum housing , integrated interface system.It's light and handy ,making
installation easier. It's the ideal inverters for small PV plants ,
or individually for small houses both indoors and outdoors.
Features:
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
1.Pure sine wave inverter
2.Built-in PWM solar charge controller
3.Selectable input voltage range for home appliances and personal computers
4.Selectable charging current based on applications
5.Configurable AC/Solar input via LCD setting
6.Compatible to mains voltage or generation power
7.Auto restart while AC is recovering
8.Overload and short circuit protection
9.Smart battery charger design for optimized battery performance
10.Cold start function
Technical Parameter
Wi-Fi GPRS Kit Inbuilt MPPT 48V80A solar controller 5KW Off Grid Hybrid High frequency solar inverter
|
RATEDPOWER |
5000VA / 5000W |
|
Parallel Capability |
Yes,9units |
|
INPUT |
|
|
Voltage |
230 VAC |
|
Selectable Voltage Range |
170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliance) |
|
Frequency Range |
50 Hz/60 Hz (Auto sensing) |
|
OUTPUT |
|
|
AC Voltage Regulation (Batt. Mode) |
230 VAC ± 5% |
|
Surge Power |
10000VA |
|
Efficiency (Peak) |
90% |
|
Transfer Time |
10 ms (For Personal Computers) ; 20 ms (For Home Appliances) |
|
Waveform |
Pure sine wave |
|
BATTERY |
|
|
Battery Voltage |
48 VDC |
|
Floating Charge Voltage |
54 VDC |
|
Overcharge Protection |
66VDC |
|
SOLAR CHARGER & AC CHARGER |
|
|
Max. PV Array Open Circuit Voltage |
500VDC |
|
Max. PV Array Power |
4500 W |
|
MPP Range @operating Voltage |
120~430VDC |
|
Max. Solar Charge Current |
80 A |
|
Max. AC Charge Current |
80 A |
|
Max. Charge Current |
80 A |
|
PHYSICAL |
|
|
Dimension, D x W x H (mm) |
120 x 295x 468 |
|
Net Weight(kgs) |
11 |
|
Communication Interface |
USB/RS232 |
|
ENVIRONMENT |
|
|
Humidity |
5% to 95% Relative Humidity (Non-condensing) |
|
Operating Temperature |
-10° C to 55° C |
|
Storage Temperature |
-15° C to 60° C |
Contact KiKi Tan
Technic &QC
Workshop
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
Our project
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
Our Company
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
Our Certificates
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
Our Clients Feedback
ESG Wholesale MPPT 48V80A controller 3KW 5KW 8KW ON Off Grid Hybrid High frequency solar inverter
FAQ
1, Why choose our company?
Since 1987, 32years brand . It is National Government Bidding Project, Designating One of the
Five Major Suppliers.
2.How about our quality .
100% on-line inspection before shipment. Effective control of nonconformity rate at 0.1%.
When your client Overuse 'charger or discharger the battery the let the battery faulty .we
can use our patented instruments to help you analyze the battery problems. repair it .at the
same time, help you reduce unnecessary losses, and get more customers to win over
competitors.
3.How about the payment term?
Multiple Payment Available : T/T L/C D/A D/P OA 30-90 days.
4.How about the price cost.
We have good anvantagement . compare other supplier price cheaper more that 10% .
(The battery case and plate are designed and manufactured by our company save over 10%,
5.How many Brand?
Brands:TOYO&. HKTOYOL.& ESG etc 3 brand 5 series products, - Agent locate more than
20 countries.
6. Certification
ISO CE TUV SGS SONCAP certification supply for The National Customs Clearance.
7. Delivery time
1-2days. We keep hot sell model stocks. 50 Production Lines , Full automatic line operation.
The 12v7ah battery 20000pcs/day
8.How to cooperation .
Free sample for you testing the quality.
9.Are you factory or trade company .
We are factory. We invest over 10 Alibaba shop.Because different account different name.
So the alibaba account all show on trade company type.
10.Which goods do you can deal?
Our company has developed a diversified business model. It mainly produces batteries.
Solar energy peripheral supporting sales. Our products are as follows:
1. Solar pump
2. Wind turbine
3. Solar panel . portable solar system
4. Controllers (PWM controllers .MTTP Controllers)
5. Inverter (High frequance .Pure sine wave inverter)
6. LED Street Lighting ( wind and solar lighting .All in one )
ESGWholesale price Wi-Fi GPRS Kit Inbuilt MPPT 48V80A solar controller 5KW Off Grid Hybrid High frequency solar inverter
