*Safety The primary stress points are centered in the hub, and the vertical blade and triangular double fulcrum designs are used, providing a better solution to the problems of blade coming off, fracture, and flying out.
* Noise To minimize noise to a level that cannot be detected in the natural environment, horizontal plane rotation and blade designs based on aviation wing principles are used.
* Resistance to wind The triangular double fulcrum and horizontal rotation of the integrated blade's design make it less susceptible to wind pressure, and it can withstand super typhoons. The integral blade is composed of aluminum alloy.
* Spinning circle It has a lower turning radius than other wind power generating methods due to its unique design structure and operating principle, which also saves space and increases efficiency.
*Characteristics of the generation curve Compared to other types of wind turbines, the beginning wind speed is lower, and the growth in power output is rather gradual. As a result, its power output is 10% to 30% higher than that of other types of wind turbines in the wind speed range of 5 to 8 m.
* Using a variety of wind speeds In order to increase overall power output while making the most use of wind resources and increase the economics of wind power equipment, the appropriate operating wind speed range is expanded to 2.5 – 25 m/s.
*Braking system Speed protection is built into the blade itself, and mechanical manual and electrical automated brakes are both available. Only manual brakes can be set in locations free of typhoons and super gusts.
* Operational Temperature: -40°C-80°C * Magnet: NdFeB
* Wind Direction Adjustment: Automatically Change The Windward Angle * Blade Material: Aluminum
* Generator Type: three-phase permanent magnet ac synchronous generator
* Braking method: electromagnetic brake
